Pattern ID Pattern Name MT LT LT180 LT80 HT GT WT VT NP1000 NP3150 NP905 NP4000 NP4100 NP62 NP64 NP3250 NP216

02H Cross Hatch x * * x * x x x x * * * * * * * *

03H Gray Bars ** * * * * ** * * * x x x x * X

04H Raster(0%) * * * * * * * * * * * * * * * * *

05H Raster(25%) * * * * * * * * * * * * * x x * *

06H Raster(50%) * * * * * * * * * * * * * x x * *

07H Raster(100%) * * * * * * * * * * * * * * * * *

08H Focus * * * * * * * * * x x x x x x x x

09H Raster Blue * x x * x * x * * * * * * * * * *

0AH Gray Raster 30 * * * * * * * * * * * * * * * * *

17H Gray Raster 10 * * * * * * * * * * * * * * * * *

18H RAMP WBRG x * * x * x * x x x x x x * * x *

19H Blue Raster 60 x * * x * x * x x x x * * * * x *

1DH Cross Hatch 3 * *1 * * x * * * * x x x x x x x x

* : Supported

x : Not supported

*1: Only LT240K/260K

DATA34 Test pattern display 2

FFH: No display (Normal condition)

FFH Other: Displaying

Bit 2: BLUE pattern

0 = OFF

1 = ON

Bit 1: GREEN pattern

0 = OFF

1 = ON

Bit 0: RED pattern

0 = OFF

1 = ON

DATA35 .. 50 Reserved

DATA51 .. 65 User registration name ( 14 characters + NULL )

DATA66 Forced On-screen mute

00H : OFF

01H : ON

DATA67 On-screen display

00H : No display

01H : Displaying

DATA68 Selecting signal processing

00H : No execution (Normal condition)

01H : During execution

DATA69 Status of operation

00H : Idling

04H : Power On

05H : Cooling

06H : Idling (Error occurrence)

Other than above: (nondisclosure)

Internal use of code during a state transition period

DATA70 .. 71 Projector type
